1200W 960Wh Portable Power Station with XT60 Fast Charging for Outdoor Emergencies
Basic Properties
Place of Origin:
China
Brand Name:
shunxiang
Certification:
CE,ROSH,FCC,UN38.3
Model Number:
F38
Trading Properties
Minimum Order Quantity:
20
Payment Terms:
T/T
Supply Ability:
1000pcs/month
Specifications
| Product Model: | F38 | Battery Types: | LIFEPO4 |
| Rated Power: | 1200W | Capacity: | 960Wh |
| Size: | 380*220*180mm | G.W: | 14.5 Kg |
| High Light: | 1200W Portable Power Station,960Wh Energy Storage Power Supply,XT60 Fast Charging Portable Energy Storage |
||
Product Description
1200W Portable Energy Storage Power Supply with XT60 Fast Charging for Outdoor Emergencies
Product Specifications
| Product Name | Portable Energy Storage Power Supply |
|---|---|
| Product Model | F38 |
| Battery Type | LIFEPO4 |
| Capacity | 960Wh |
| DC Input | XT60 30-60V 450W |
| AC Inverter Output | 110V/60Hz, 1200W MAX 220V/50Hz, 1200W MAX (Optional) |
| USB Output | USB-1: 5V3A, 9V2A, 12V1.5A (QC18W) USB-2: 5V3A, 9V2A, 12V1.5A (QC18W) |
| DC Output 5521 | 12V 5A |
| Size | 380*220*180mm |
| Gross Weight | 14.5 kg |
| Operating Temperature | Charging: 0-45°C Discharging: -20-60°C |
| Workplace Humidity | 65±20% |
| Storage Temperature | 25±5%℃ |
User Manual
Charging Input
Charge this product using the original adapter or power cable. The device is charged via the XT60 MPPT converter.
Output Specifications
- USB Ports:
- USB1: 5V 3A, 9V 2A, 12V 1.5A (QC18W)
- USB2: 5V 3A, 9V 2A, 12V 1.5A (QC18W)
- DC Direct Output 5521 Terminal: 12V 5A
- Turn on the AC power switch; the digital display illuminates. The AC outlet outputs 220V AC at 1200W.
Operation Guidelines
- Insert USB to automatically wake up and initiate discharge.
- In case of abnormal operation, immediately shut off the power output and unplug the device.
- After use, unplug the power cord and turn off the power.
- When the battery voltage is too low, the product will enter low-voltage protection mode and cease voltage output.
- When using the AC output port, ensure the device load power does not exceed the product's rated power of 1200W.
- When the battery enters low-voltage mode, recharge it promptly.
