6000W Peak Power Portable Power Station with 110V/220V AC Output and Low Voltage Alarm
| Continuous Power: | 3000W | Peak Power: | 6000W |
| Input Voltage: | 12 VDC | Input Voltage Range: | 9.5–15.5 VDC |
| AC Output Sockets: | 2 | Communication: | RS-485 |
| Peak Power | 6000W |
| Continuous Power (Resistive Load) | 3000W |
| Output Efficiency | ≥87% |
| Output Voltage | 110 VAC / 220 VAC |
| Output Frequency | 50 Hz / 60 Hz |
| Output Waveform | Pure Sine Wave |
| Total Harmonic Distortion (THD) | <5% (Linear Load) |
- Low Voltage Alarm: 9.5 VDC
- Low Voltage Protection Shutdown: 9 VDC
- Overvoltage Protection Shutdown: 16 VDC
- Over-Temperature Protection: ≥70°C (Inverter Output Shutdown)
- Short-Circuit Protection
- Intelligent Cooling System with Dual Fans
| Input Voltage | 12 VDC |
| Input Voltage Range | 9.5-15.5 VDC |
| AC Output Sockets | 2 |
| Communication | RS-485 |
| LCD Display | Shows battery voltage, charge level, AC voltage, AC frequency, error codes, and fan status |
| Terminals | Screw-tightened positive and negative connections |
| Operating Temperature | -20°C to 60°C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Temperature | -40°C to 70°C |
| Storage Humidity | 10% to 95% RH (non-condensing) |
| Operating Altitude | ≤3000 m (Derated operation above 1000 m) |
| Product Dimensions | 455 * 208 * 94 mm |
| Product Weight (Net) | 5.75 kg |
| Packaging Dimensions | 522 * 268 * 155 mm |
| Packaging Weight (Gross) | ≈6.7 kg |
10200W Solar System Inverter 160A Solar Charge 360V DC Hybrid Solar Inverter
10200W Pure Sine Wave MPPT Hybrid Inverter All-in-One for Solar System 10200W Off-Grid Hybrid Solar Inverter | All-in-One Power Solution This high-power hybrid inverter is designed for off-grid systems, efficiently converting 48V DC power to 220V/230V/240V AC single-phase output. Its built-in 160A MPPT solar charge controller maximizes solar energy harvesting. By integrating the functions of an inverter, solar charger, and battery charger into a single unit, it provides a
8200W Solar System Inverter Hybrid Solar Inverter 450V DC Pure Sine Wave MPPT Inverter
Key Features Pure sine wave solar inverter(on/off Grid) Output power factor 1.0 WIFI&GPRS available for IOS and Android Inverter can run without battery One-key restoration to factory Settings Built-in Lithium battery automatic activation Built-in 160A MPPT solar charger(for 8.2kw,10.2kw) Dual communication ports for Battery communication and Wifi communication High PV input voltage range(90~500VDC) Built-in anti-dust kit for harsh environment Smart battery charge design to
6500W Solar Panel Inverter With 120A High Current And 500V Input For Efficient Power Conversion
Control Panel Components LCD display Status indicator Charging indicator Fault indicator Function buttons Power on/off switch AC input Main output Second output Battery input PV input Antidust kit WIFI communication/RS-232 port Battery communication/RS-485 port Insert the battery wires flatly into battery connectors of inverter and make sure the bolts are tightened withtorque of 2 Nm in clockwise direction. Make sure polarity at both the battery and the inverter/charge
4200W Solar Battery Inverter With 120V Pure Sine Wave Output And MPPT Charge Controller
4200W Hybrid Solar Inverter with 120A MPPT Charge Controller and 110V/120V Pure Sine Wave Output Product Specifications MODEL VICTORNM-ECO-3.6KW PLUS VICTORNM-ECO-4.2KW PLUS VICTOR NM-ECO-6.2KW PLUS Phase 1-phase Maximum PV Input Power 6200W 6500W 6200W 6500W Rated Output Power 3600W/3600VA 4200W/4200VA 6200W/6200VA Maximum Solar Charging Current 120A 80A 120A GRID-TIE OPERATION PVINPUT(DC) Nominal DC Voltage/Maximum DC Voltage 360/500VDC Start-up Voltage/Initial Feeding
